AvL 1610 Premium SNG 1.6m Motorized Vehicle-Mount Satellite Antenna Precision Ku-Band

AvL 1610 Premium SNG 1.6m Motorized Vehicle-Mount Satellite Antenna Precision Ku-Band

AvL 1610 Premium SNG 1.6m Motorized Transportable Vehicle-Mount Satellite Tx/Rx Antenna 2-Port Mode-Match Ku-Band (standard Cross-Pol comp.)

IKtechcorp is the distributor for AVL Antanna Systems, a leading manufacturer and supplier of commercial satellite equipment. AVL Technologies offers a wide range antennas used in the VSAT, DTH, COTM, Teleport, Cable, and Broadcast industries. Satellite, DTH, VSAT, Flyaway, quick deploy, receive only, RF, motorized auto point, vehicle antennas.
• Rx/Tx Feed: 2-Port Precision Ku-Band (LP)
- Receive: 10.95 - 12.75 GHz
- Transmit: 13.75 - 14.50 GHz
- Standard Cross-Pol comp.
Stows to 17.7" H (45 cm H)
• Key Features
- Lightweight and Low-Profile
- 3-Axis Jog Controller w/ Auto-Stow
- Zero backlash AvL Cable Drive
- 400° Az & 0-90° El Movement

Product Code: avl_1610_ku_premium

AvL 1610 Premium SNG 1.6m Motorized Transportable Vehicle-Mount Satellite Tx/Rx Antenna 2-Port Mode-Match Ku-Band (standard Cross-Pol comp.)

AvL 1610 Premium SNG / Military 1.6m Motorized Transportable Vehicle-Mount Satellite Tx/Rx Antenna 2-Port Mode-Match Ku-Band (standard Cross-Pol comp.)  Product Picture, Price, Image, Pricing


Summary

AvL 1610 Premium SNG 1.6m Motorized Transportable Vehicle-Mount Satellite Tx/Rx Antenna 2-Port Mode-Match Ku-Band (standard Cross-Pol comp.)

AvL's 1.6m vehicle-mount / drive away SNG antenna systems offer strong performance in a small, lightweight and low-profile package. The 1.6m antenna systems enable Ku, L and C-band communications with integrated GPS and level sensors for automatic vehicle tilt compensation.

AvL’s SNG antennas  are designed to meet and exceed the highest performance requirements around the world to guarantee both satellite authority compliance and peak in performance, reliability and availability. Typically these antennas are used in signal contribution for high data rate and bandwidth as well as high power broadcast or similar applications.

AvL 1610 Ku-Band Vehicle-Mount Premium SNG Antenna Systems feature:
• High-precision azimuth bearing
• Non-load-bearing 1.6m AvL carbon fiber single-piece reflector with surface treatment for Ka-band
• Integrated reflector backing structure for minimized stow height
• Wide booms to allow larger HPA envelope
• Jog control or fully automatic auto-acquisition controllers
• Feed options for Ku-, Ka- and X-band; optional C-band for international
• RF electronic mounting either on feed boom, back of reflector, base, or inside vehicle
• 25ft (8m) RG59 coax and controller interconnect cables
• Zero backlash AvL Cable Drive with 400° Az & 0-90° El movement
• Stows to 17.7" H (45 cm H)
• Optional saddlebag mount for larger HPAs
• High-torque elevation motor
• Through-pedestal cross-axis waveguide kit
• Optional Transmit Rotary Joint on Feed
• Limited function 3-axis jog controller with auto-stow
• Optional aerodynamic cowlings
• Aerodynamic cowling is available






Technical Specifications Diagram
